Build Specs
RearShock | Fox Performance Float |
Fork | Fox Performance 34SL 29", 44mm offset, GRIP - 120mm |
Headset | Pivot Precision Sealed Integrated Cartridge |
RearDer | Shimano XT Di2 M8200 SGS 12-Speed |
Shifter | Shimano XT Di2 M8200 ISPEC EV 12-Speed |
Cassette | Shimano XT M8200 10-51t |
Chain | Shimano CN-M8100 12-Speed |
Crankset | Race Face Æffect R 34t |
Brakes | Shimano XT M8200 2-piston |
Rotor | Shimano RT-86 6-bolt - 180mm<br/>Shimano RT-86 6-bolt- 160mm |
Handlebar | Phoenix Team Flat Carbon - 760mm |
Grips | Phoenix Factory Lock-On |
Stem | Phoenix Race XC/Trail - 60mm |
Seatpost | TranzX YSP23GLS |
Saddle | Phoenix WTB Race Volt (Narrow Width) |
Wheels | DT Swiss X1900 w/ DT Swiss 370 hub, 25mm - 29" <br> 15x110 F/12x148 R |
Tires | Maxxis Ardent Race 29" x 2.2" TR, EXO, 120 TPI<br />Maxxis Ardent Race 29" x 2.2" TR, EXO, 120 TPI |
Product Details
Ultralight Hollow Core Carbon Frame
XC-Tuned dw-link™ Suspension
XC Adapted Travel-Adjustable Flip-Chip
Rear Travel Options from 110 to 120mm
Size-Specific Carbon Layup Across Size Range
Low Standover Fits Riders 4’10” to 6’ 7”
Full Internal Routing with Pivot Cable Port System
120mm Fork
Pivot’s Toolshed™ Downtube Storage
Large Water Bottle Clearance on All Sizes
Injection Molded Rubberized Frame Protection
Pivot Dock Tool System Compatible
